FBE coated ductile iron pipe is pipe with an interior of epoxy ceramic made of epoxy resin, quartz powder and others with a dry film thickness of more than 1,000μm,and the excellent corrosion resistance electrical insulating property makes it be a preferential position in transporting municipal sewage, reclaimed water, etc.
Factory applied coating with Pure as a binder such as:
Fusion bonded epoxy powder applied by spraying or dipping in fluidized bed on preheated parts,
Two-pack liquid epoxy consisting of a base and a catalyst compeonent which is mixed together in the proportion specified by the manufaturer before use.
The epoxy coating of the final product shall be of uniform color, except for permitted marking;
Uniform appearance and smoothness, except for admissible repairs;
Free of visible defects(pinholes, bubbles, blisters, wrinkles, cracks or voids).
| Type: | The T-type Joint Pipe (Push-on) |
| The K-type Joint Pipe | |
| The Self-Restrained Joint Pipes | |
| Standard: | ISO2531, EN545, EN598, etc |
| Size: | DN80~2600mm |
| Material: | Ductile Cast Iron GGG50 |
| Pressure: | PN10, PN16, PN25,PN40 |
| Class: | K9, K8, C25, C30, C40 |
| Length: | 6m, cut to 5.7m |
| Application: | Water supply project, drainage, sewage, irrigation, water pipeline. |
| Certificate: | ISO9001, BV, WRAS, SGS |
| Internal Coating: | a). Portland cement mortar lining |
| b). Sulphate Resistant cement mortar lining | |
| c). High-Aluminum cement mortar lining | |
| d). Fusion bonded epoxy coating | |
| e). Liquid epoxy painting | |
| f). Black bitumen painting | |
| External Coating: | a). zinc+bitumen(70microns) painting |
| b). Fusion bonded epoxy coating | |
| c). Zinc-aluminum alloy +liquid epoxy painting | |
| Packing: | Bundles, in bulk |
| Note: The coating can also be accordance with customers’ requirements. | |
